Pie Chart
The PieChart React component presents data as proportional slices of a circle, ideal for showing percentage breakdowns. It includes label support, tooltips, and interactive hover effects.
The PieChart component is used to visualize data in a pie chart format. It is a wrapper around the Recharts PieChart component.
Usage
import { PieChart } from "@sparrowengg/twigs-charts";
const Chart = () => {
return (
<PieChart
data={[
{
name: "Jan",
value: 4000,
color: "$list.0",
},
{
name: "Feb",
value: 3000,
color: "$list.1",
},
{
name: "Mar",
value: 2000,
color: "$list.2",
},
{
name: "Apr",
value: 2780,
color: "$list.3",
}
]}
size={200}
/>
);
};Props
| Prop | Type | Default |
|---|---|---|
cellProps? | CellProps | (cellData: DonutChartData) => ComponentProps<typeof Cell> | - |
pieProps? | PieProps | - |
chartProps? | PieChartProps | - |
containerProps? | React.HTMLProps<HTMLDivElement> | - |
unit? | string | - |
highlightOnLegendHover? | boolean | - |
defaultActiveIndex? | number | - |
animationDuration? | number | - |
renderLegendIcon? | (data: Payload) => ReactNode | - |
valueFormatter? | (value, info) => string | null | - |
paddingAngle? | number | 0 |
showTooltip? | boolean | true |
showLegend? | boolean | true |
showLabelLine? | boolean | false |
showLabel? | boolean | false |
size? | number | 200 |
height? | string | number | 300 |
width? | string | number | 100% |
data | Array<{ name: string, value: number, color: string }> | [] |
Examples
Default Active Value
A value can be set as default active value by setting the defaultActiveIndex prop.
With Unit
A unit can be set by setting the unit prop.
With Value Formatter
With Custom Legend Icon
